Spesifikasi
Parameter Fungsi | |
Nominal Battery Energy | 3900wh |
Nominal Kapasitas | 65Ah |
Nominal Tegangan | 60V |
Resistensi Internal | 22mΩ |
Siklus Hidup | >6000 |
Bulan Self Discharge | <3% |
Mengisi Data | |
Tegangan Pengisian Normal DC | 54,75 ± 1Vdc |
Mode Pengisian | 0.2C ke 54.75V, lalu 54.75V, isi arus ke 0.02C (CC/CV) |
Direkomendasikan Pengisi Daya Saat Ini | 50A |
Diizinkan Maks. Mengisi Arus | 50Adc |
Isi Daya Cut-off Voltage | 54,75 ± 1Vdc |
Data Debit | |
Arus Debit Kontinyu | 50A |
Diizinkan Maks. debit arus | 100A (opsi: 100Adc) |
Rang dari tegangan pelepasan DC | 37.5V-54.75Vdc |
Situasi kerja | |
Mengisi Suhu | 0℃ hingga 45℃ (32℉ hingga 113℉) @60±25% Kelembaban Relatif |
Suhu Discharge | -20℃ hingga 60℃ (-4℉ hingga 140℉) @60±25% Kelembaban Relatif |
Suhu Penyimpanan | 0℃ hingga 40℃ (32℉ hingga 104℉) @60±25% Kelembaban Relatif |
Tingkat Perlindungan Kandang | IP67 |
fitur
1.Rechargeable battery
2.Use of Iron(Fe) as a cathode material
3.Higher discharge current
4.Do not explode under extreme conditions and weight less
Keuntungan
1.Extremely high rate capability
2.Safe lithium battery
3.Good storage characteristics
4.Good high temp performance
5.Long cycle life to 2000 times
6.High capacity & light weight
7.Environmentally friendly
8.No memory effect
We can provide you with customized services
Customized 7.4V-12V-24V-36V-48V-52V-60V-72V...LITHIUM BATTERY PACK
The capacity and dimension can customize according to your request:
1.Customized battery size and shell material
2.Customized BMS charging and discharging current
3.Customized connect plug and socket, connector wire
AIN Aplikasi Utama Paket Baterai Lithium | |
Aplikasi penggerak listrik | baterai start mesin; Mobil Kecepatan Lambat; robot intelektual; sepeda listrik / sepeda motor / skuter; troli golf / gerobak / mobil tamasya; alat-alat listrik. |
Penyimpanan energi | sistem tenaga surya dan angin; kota on / off grid; komunitas dan keluarga, RV Caravan, Marine yachts. |
Sistem cadangan dan UPS | Telecommute base, CATV-system, computer server center, medical instrument, military equipment. |
Aplikasi lain | keamanan dan elektronik; POS seluler, lampu pertambangan / obor / lampu LED / lampu darurat. |
Perusahaan kita
WHY CHOOSE US?
1.Our company has 13 years experience in battery R&D,producing and the overseas marketing.
2.Flexible customizing and Manufacturing
3.6,000,000Ah monthly production capacity
4.Each process for making battery were under strict management and control,all of the battery were under full inspection before delivery.
5.With professional R&D team, experienced workers and advanced requirements, we are determined to provide you high-quality battery.
6.Support prompt shipment and sample quality products,track the cargo in time after delivery.More than one year Guarantee,we will give instruction for how to use our products.
FAQ
Q: What is your warranty?
A: We guarantee the quality before the item is shipped. The warranty will be offered based on different type of battery. Any damages caused by improper use are not covered by our warranty.
Q: What is delivery time if we place an order?
A: It depends order quantities. Usually, we can deliver goods within 3 -5 working days for small orders, for more QTY. order, let's confirm when you place offical order.
Q: Are your factory or trading company?
A: We are professional lithium-ion rechargeable batteries manufacturer with our own factory and brand. We provide all kinds of OEM/ODM services for clients around globe.
