Spesifikasi
Tegangan Nominal | 72V |
Kapasitas nominal | 50Ah |
Resistensi Internal | ≤220mΩ |
Siklus Hidup | 2000 times at 85% dod 5000 times at 65% dod 8000 times at 40% dod |
End of charge Voltage | 14.6V |
End of charge Current | 100mA |
Max.Continuous charge current | 50A |
Metode Pengisian | 0.2C (0.5A) CC/CV |
End of discharge Voltage | 9.2V |
Max. Pluse Discharge Current | 50A/10S |
Charge Temp | 0 ~ 45 ℃ |
Discharge Temp | -10~55℃ |
Storage Temp | -10 ~ 45 ℃ |
Dimension(D×W×H) | 332*170*220mm |
Bobot | ≤20Kg |
Dibangun di Sistem Perlindungan Baterai Otomatis | Iya |
Charge plugs and Discharge connectors optional
1.Charger Plug: US EU UK AU plugs optional, will provide according to delivery country if without request
2.Discharge Connector: There are 12 kinds optional as below picture, will provide naked cable or soldered with default connector if without requested.
fitur
1.Lighter weight, smaller size
2.High temperature performance
3.Extremely safe, no explosion, no fire under collision
4. Resistensi over-discharge yang kuat dan retensi biaya
5.Strong charging acceptance and quick-charging capability
6.Maintenance-free and no acid or water for maintenance in usage
7.Large capability and long life for all high power output applications
8.Environmentally friendly non-toxic, non-contaminating, no rare metal.
9.Low self-discharge and good discharge performance at low temperature
10.Excellent large current discharge performance especially in startup and climbing
OEM
We also can customize the battery 12v/24v/36v/48v/72v 100h,120ah,200ah,300ah,400ah,800ah with metal box. The size and shape are flexible according to your given size. And if necessary, we can offer a remote LCD display to monitor the battery status.
To welcome the world cooperation we accept OEM with your logo design.
Aplikasi
Aplikasi
* Electric Vehicles for Commercial and Commuting * Electric Scooter * Golf Cart/ troller * Electric Mobility * Electric Motorcycle * Electric Bicycle * Electric Wheelchair * Electric Power Mower * RV (Recreational Vehicle) * AGV (Automatic Guided Vehicle) /AGV cars/ AGV robots/ Self-guided
Pabrik kami
FAQ
1,Q: What's the main product in AIN?
A: Rechargeable battery. NiMH, Li-ion, Lipo battery and power battery pack.
2, T: Apa itu overcharge?
A: After charge, tested the batteries' initial state and capacity. Charge to 10.0V at 3C current, then charge to 0.01C at CV mode.
Observe changes in battery appearance.
3, T: Apa itu over discharge?
A: After charge, test the batteries' initial state. When the batteries are normal, discharge to 0V at 0.5C. Observe changes in
battery appearance.
4. Q: Dapatkah saya memesan sampel?
A: Ya, kami menerima pesanan sampel untuk menguji dan memeriksa kualitas. Baterai dapat dibuat sesuai kebutuhan.
5. Q: Apakah Anda memiliki batas MOQ?
A: Ya, kami memiliki batas MOQ untuk produksi massal, tetapi itu tergantung pada model baterai. Silakan hubungi kami untuk detailnya.
6. T: Bagaimana dengan lead time?
A: Sampel akan memakan waktu 5-7 hari kerja. Produksi massal akan memakan waktu 25-30 hari. Itu tergantung kuantitas.
7. Q: Bagaimana dengan pengiriman dan waktu pengiriman?
A: Generally, battery will be shipped via Express, such as DHL, TNT, FedEx and UPS, delivery time is 3-5 business days. Or DDP service, delivery time is 11-15 business days. Airline and sea shipping also available.
8. Q: Bagaimana dengan layanan purna jual?
A: We will offer you 2 years guarantee. If there are any problems, please inform us, we will offer you positive solutions.
