Spesifikasi
Kelistrikan | Tegangan Nominal | 12.8V |
Kapasitas nominal | [email protected] | |
Energi | 3840Wh | |
Resistensi Internal | ≤35mΩ | |
Siklus Hidup | 2000-6000 Cycles @ 0.2C Charging/Discharging ,Until 70% Capacity | |
Self Discharge | ≤3,5% per bulan pada 25 ℃ | |
Pengisian Standar | Max. Pengisian Tegangan | 14.0 ~ 14.6V |
Mode Pengisian | Pada suhu 0 ℃ ~ 45 ℃, dibebankan ke 14.6V pada arus konstan 0.2C, dan kemudian, diubah terus menerus dengan tegangan konstan 14.6V hingga arus tidak lebih dari 0.02C | |
Pengisian Saat Ini | 100A | |
Max. Pengisian Saat Ini | 100A | |
Pengosongan Standar | Pengosongan Saat Ini | 100A |
Max. Arus Kontinyu | 100A | |
Max. Arus Pulsa | 200A (<3S) | |
Pengosongan Tegangan Cut-off | 10.0 | |
Kondisi Operasi | Mengisi Suhu | 0 ℃ hingga 45 ℃ (32 ℉ hingga 113 ℉) @ 60 ± 25% Kelembaban Relatif |
Suhu Discharge | -20 ℃ hingga 60 ℃ (-4 ℉ hingga 140 ℉) @ 60 ± 25% Kelembaban Relatif | |
Suhu Penyimpanan | 0 ℃ hingga 45 ℃ (32 ℉ hingga 113 ℉) @ 60 ± 25% Kelembaban Relatif | |
Tahan Debu Air | IP55 | |
Struktur | Sel & Format | 4S1P, prismatic |
Selubung | Plastik | |
Dimensi (L * W * H * TH) | 522*270*217*217mm | |
Bobot | Approx. 27.5Kg | |
Terminal | M8 |
Can add LCD fuel gauge.
Can add Control switch.
Can add Coulomb lamp display.
Can add USB connector.
◆ Menggunakan teknologi sel lithium besi fosfat, keamanan unggul, ribuan siklus, 100% DOD, dalam kondisi normal.
◆ Proteksi otomatis bawaan untuk pengisian berlebih, pelepasan muatan berlebih, suhu berlebih dan suhu berlebih.
◆ Bebas perawatan.
◆ Keseimbangan sel internal.
◆ Berat lebih ringan: Sekitar 40% ~ 50% dari berat baterai asam timbal yang sebanding.
◆ Dapat diisi menggunakan sebagian besar muatan asam timbal standar (set).
◆ Kisaran suhu yang lebih luas: -20 ℃ ~ 60 ℃.
◆ Support for Series application expansion (up to 51.2V) and two in parallels.
Pabrik kami
Packing dan Pengiriman
FAQ
Q1. Is it OK to print my LOGO on the product?
A. Ya. Mohon informasikan kepada kami secara resmi sebelum produksi kami dan konfirmasi desain terlebih dahulu berdasarkan sampel kami.
Our factory supports Customized: case, size, battery structure, logo, packaging etc.
Q2. Can I have a sample order?
A.Yes, we welcome sample order to test and check quality.
Low MOQ, 1pc for sample checking is available.
Q3:Which product is hot sale in your company?
A: LiFePO4 battery 24Ah,50Ah,100Ah,200Ah,280Ah,300Ah; 12V,24V, 48V LiFePO4 battery pack and so on.
Q4. What about the lead time?
A. Sample needs 3-7 days, mass production time needs 7-20 days, it depends on order quantity.
P5. Bagaimana cara melanjutkan pesanan?
A. Firstly let us know your requirements or application. Secondly, We quote according to your requirements or our
suggestions.Thirdly customer confirms the samples and places a deposit for formal order. Fourthly We arrange the production.
Q6.Which certificates do you have?
A: Kami memiliki CE / FCC / ROHS / UN38.3 / MSDS ... dll.
Q7.How about warranty?
A:3-5 year warranty
Q8: Are these battery packs compatible with my inverter?
A: Yes, Sir. Our battery pack is compatible with most brands of inverters on the market.
Contact us and let me tell you more.
Q9. How do you ship the goods and how long does it take to arrive?
A.It usually takes 5-7 days to arrive. Train and Airline and Sea(DDP) shipping is also optional.
Q10: How do I know whether you've shipped my order or not?
A: Tracking No. will be offered as soon as your order be shipped out. Before that, our sales will be there to check the packing
status, photo you the done order and let you know the forwarder picked it up.
