Spesifikasi
Barang | Index | Ucapan | |
Normal specification | Kapasitas yang ternilai | 20Ah | 2A charge |
5A discharge | |||
Tegangan Nominal | 48V | ||
Resistensi Internal | ≤220mΩ | ||
Bobot | 6.5±0.1kg | ||
Dimensi | 345x104x95±2mm | ||
Charge performance | charge mode(standard) | CC / CV | |
charge current(standard) | 2A | or specialized charger | |
charge voltage(standard) | 58.V | ||
Ambiance temperature | -20°C~+55°C | ||
charge time(h) | 6~8 | ||
Over-current fuse | 4A/250V(φ5.2*20mm) | ||
36v 10ah | 48v 10ah | 52v 10ah | 60v 15ah |
36v 13ah | 48v 11.6ah | 52v 10.4ah | 60v 17.5ah |
36v 14.5ah | 48v 12.8ah | 52v 11.6ah | 60v 19ah |
36v 16ah | 48v 13ah | 52v 13ah | 60v 20ah |
36v 17.5ah | 48v 14ah | 52v 14ah | 60v 22ah |
fitur
- Sistem BMS yang stabil dengan perlindungan sirkuit pendek, perlindungan biaya berlebih, perlindungan pelepasan muatan berlebih, dan fungsi perlindungan arus berlebih.
- Dengan setidaknya Lebih dari 500 kali siklus hidup
- Ini dapat berjalan dengan baik di bawah kondisi lingkungan suhu yang berbeda
- Tidak ada efek memori.
- Cocok untuk sepeda listrik, sepeda listrik dll.
- Baterai berkapasitas penuh, pengujian kualitas 100%
- Siklus hidup yang panjang dan kepadatan energi yang tinggi
- Kapasitas, hambatan, Voltase, konsistensi waktu platform bagus
- Harga pabrik dan pengiriman cepat
- Light weight, small size
AIN Lithium Battery Main Applications | |
Aplikasi penggerak listrik | Engine starting battery; Slow Speed Car; Intellectual robots; Electric bicycle/Motorcycle/Scooter; Golf trolley/Carts/ Sightseeing car; Power tools. |
Penyimpanan energi | sistem tenaga surya dan angin; kota on / off grid; komunitas dan keluarga, RV Caravan, Marine yachts. |
Sistem cadangan dan UPS | pangkalan telekomunikasi, sistem CATV, pusat server komputer, peralatan medis, peralatan militer. |
Aplikasi lain | keamanan dan elektronik; POS seluler, lampu pertambangan / obor / lampu LED / lampu darurat. |
Pabrik kami
Why us
1,Quick response,email/skype/whatsapp/wechat etc to reply you as quick as we can.
2,Ensure the satisfiied quality,All of our products are tested one by one before shipping.
3,We can promise all the price is the factory direct sale price.
4,We are the manufacture of this product in Anhui for many years.
5,We'll try our best to assist you to solve all you want to know.
For buyers
1,online talk or inquire via e-mail to sales.
2,comfirm order(quantites,colors,size,capacity,payment terms,delivery time etc.
3,Make Proforma Invoice.
4,Arrange the payment.
5,Start the order when deposit arrived.
6,Arrange shipment after 100% payment confirmed.
7,Follow up the goods by the tracking number.
8,Goods arrived and check.
Packing dan Pengiriman
1,Q: What's the main product in AIN?
A: Baterai isi ulang. Li-ion, baterai Lipo, dan unit baterai daya.
2, T: Apa itu overcharge?
A: After charge, tested the batteries' initial state and capacity. Charge to 10.0V at 3C current, then charge to 0.01C at CV mode.
Observe changes in battery appearance.
3, T: Apa itu over discharge?
A: After charge, test the batteries' initial state. When the batteries are normal, discharge to 0V at 0.5C. Observe changes in
battery appearance.
4. Q: Dapatkah saya memesan sampel?
A: Ya, kami menerima pesanan sampel untuk menguji dan memeriksa kualitas. Baterai dapat dibuat sesuai kebutuhan.
5. Q: Apakah Anda memiliki batas MOQ?
A: Ya, kami memiliki batas MOQ untuk produksi massal, tetapi itu tergantung pada model baterai. Silakan hubungi kami untuk detailnya.
6. T: Bagaimana dengan lead time?
A: Sampel akan memakan waktu 5-7 hari kerja. Produksi massal akan memakan waktu 25-30 hari. Itu tergantung kuantitas.
7. Q: Bagaimana dengan pengiriman dan waktu pengiriman?
A: Generally, battery will be shipped via Express, such as DHL, TNT, FedEx and UPS, delivery time is 3-5 business days. Or DDP
service, delivery time is 11-15 business days. Airline and sea shipping also available.
8. Q: Bagaimana dengan layanan purna jual?
A: Kami akan menawarkan garansi 1 tahun. Jika ada masalah, mohon informasikan kepada kami, kami akan menawarkan solusi positif.
